CAN FC Series - Spare Parts for FC1337

55
ENGLISHENGLISH
Installation, use and maintenance instruction manual ▪ Ed. 07/2018 Rev. 00
E VERSION - ELECTRONIC LIGHTING
code
component
pos.
component
4000319 -
Single-pole button 3A red key
2000147 -
12V generator kit + assembly bracket
4000168 -
Universal lighting cable (-)
4000169 -
IGN lighting cable L320
4000297 -
IGN lighting cable 2 (+)
4000232 27
Burner lighting glow plug L350
4000321 27
Burner lighting glow plug L410
4000137 31
Clip for glow plug
SPARE PARTS - FC1337
The column "Pos." refers to the exploded drawing "TYPE FC1337" on page 39.
P VERSION - PIEZOELECTRIC LIGHTING
code
component
pos.
component
2000008 4
Hinge for glass lids
3000495 3
Glass lid FC1337
3000083 22
Tall rubber bushing for pan holders
3000073 1
Wire pan holder for AUX burner
3000074 1
Wire pan holder for SR burner
3000454 6
Silentblock Ø 15
4000026 29
2nd series lid stud bolt
4000170 2
Glass lid cable gland
4000224 7
Intense black screw cap
4000260 23
Black/chrome knob Ø 34
4000031 30
Universal nut for thermocouple
4000069 28
Thermocouple for fast-on magnet cock
4000025 19
Burner spreader for 2nd series AUX burner
4000021 20
Ø 55 perforated and enamelled cover 2nd series AUX burner
4000024 17
Burner spreader for 2nd series SR burner
4000019 18
Ø 75 perforated and enamelled cover 2nd series SR burner
4000318 21
Countersunk flat head screw + M2.5 x 18 DIN EN ISO 7046 GV
4000223 8
Chipboard screw to secure the hob unit
7000138 -
Glass lid flame label
4000253 26
Short piezo igniter 18 x 1.5 mm
4000321 27
Burner lighting glow plug L 410
4000232 27
Burner lighting glow plug L 350
4000137 31
Clip for glow plug
4000229 32
5 x 6 CH screw to secure the hinge and silentblock
E VERSION - ELECTRONIC LIGHTING
code
component
pos.
component
4000319 -
Single-pole button 3A red key
2000147 -
12V generator kit + assembly bracket
4000168 -
Universal lighting cable (-)
4000169 -
IGN lighting cable L320
4000297 -
IGN lighting cable 2 (+)
4000232 27
Burner lighting glow plug L350
