Candy CDCP 6/E - Drain Hose Connection

Connection of drain hoses
Insert the drain hose into a drain pipe with a minimum diameter of 4cm, or let it
run into the sink, making sure to avoid bending or crimping it. The free end of the
hose must be at a height lower than 60cm and must not be immersed into water to
avoid the backflow of it.
17
MAX600mm
A
Counter
Front
Drain pipe
NOTE
The top of the hose
must be less than
600mm.
φ 40mm
B
PLEASE HANG UP THE DRAIN HOSE EITHER WAY OF A, B
