3.Operation Instruction
3
Dishwasher Features
Control Panel
before using it for the first time.
To get the best performance from your dishwasher, read all operating instructions
IMPORTANT
Filter assemblyDetergent Dispenser
Cup Shelf
Cutlery Basket
Rinse Aid Dispenser
Drain pipe connector
Inlet pipe connector
Spray Arms
Basket
1
Salt Container
5
6
7
8
9
10
3
2
4
Back View
Front view
9 10
7
8
1
2
3
4
5
6
2
3
6
7
Rinse Aid Warning Light : To be on when the
rinse aid dispenser needs to be refilled.
Washing Program Selector: Press the button
to select wash cycles.
Start/Pause Button: Press this button to start
or pause the dishwasher, the process pilot
lamp will be blinking when starting.
8
5
1
2
3
4
6
7
Power Button: To turn on/off the power supply.
Delay Button :Press the button to set delay time.
Delay time:2/4/8 hours option
.
Program indicator light.
Salt Warning Light : To be on when the softener
needs to be refilled.
2H_->4H->8H->0

Candy CDCP 6/E Specifications

General

Door color	White
Door hinge	Standard
Control type	Buttons
Product size	Compact
Custom panel-ready	-
Appliance placement	Countertop
Lower basket safety stop	Yes
Upper basket adjustable height	No
Cycle time	195 min
Noise level	51 dB
Drying system	Condensation
Delay start (max)	8 h
Dishwashing programs	Eco, Quick
Left-on mode duration	999 min
Number of place settings	6 place settings
Number of washing programs	6
Maximum hot water supply temperature	60 °C
Current	6 A
Power plug type	Type F (CEE 7/4)
AC input voltage	230 V
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (left-on)	0.45 W
Water consumption per cycle	7 L
Energy consumption per cycle	0.62 kWh
Package depth	605 mm
Package width	555 mm
Package height	503 mm
Package weight	25000 g
Drying class	A
Annual water consumption	1960 L
Annual energy consumption	174 kWh

Weight and Dimensions

Depth	500 mm
Width	550 mm
Height	438 mm
Weight	21000 g
