Candy CSOW 4963TWCE-80 User Manual

!
16
7. QUICK USER GUIDE
This appliance automatically adjusts the
level of the water to the type and quantity of
washing. This system gives a reduction in
energy consumption and a saving in
washing times.
! Turn on the appliance and select the
required program.
! Adjust the washing settings if necessary
and select the required options.
! Press the programme start button.
! The end of the programme will be
indicated by a message on the display
(on some models, all the indicator lights
on the stage will light up).
! Turn off the appliance.
For any type of wash, see the program
table and follow the operating sequence
as indicated.
Water pressure:
min 0.05 Mpa / max 0.8 Mpa
(0.05 MPa dispenses approximately 1 litre
of water in 10 seconds)
Spin r.p.m.: See rating plate.
Power input / Power current fuse amp /
Supply voltage: See rating plate.
8. CONTROLS AND
PROGRAMS
A
A
BDCEGF
I
H
H
I
BDCE GF
* Depending on model
A
Programme selector with OFF
position
B
START/PAUSE button
C
DELAY START button
D
DRYING SELECTION button**
E
RAPID / STAIN LEVEL button
F
TEMPERATURE SELECTION
button
G
SPIN SPEED button
F+G
CHILD LOCK
H
Digital display
I
DOOR LOCKED indicator light
** DRYING SELECTION/STEAM
button (only available on certain
models)
Program selection
DRYING (WASHER-DRYERS only)
If you would like the drying cycle to
begin automatically after washing,
select the washing programme
required and select the drying cycle.
Or you can finish the wash and then
select the drying programme.
Technical data

Candy CSOW 4963TWCE-80 Specifications

General

Door color	Chrome
Door hinge	Left
Motor type	Brush
Water fill	Cold
Display type	LED
Loading type	Front-load
Certification	Woolmark
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Drying system	Condensation
Drying capacity	6 kg
Washing capacity	9 kg
Delay start (max)	24 h
Residual moisture	53 %
Spin-drying class	B
Cycle time washing	228 min
Maximum spin speed	1400 RPM
Noise level (spin)	81 dB
Noise level (wash)	60 dB
Noise level (drying)	61 dB
Number of drying programs	3
Number of washing programs	14
Cycle time washing & drying	470 min
Cycle time (quick washing program)	14 min
Washing class	A
Country of origin	China
Annual water consumption washing	13600 L
Annual energy consumption washing	234 kWh
Annual water consumption washing & drying	27000 L
Annual energy consumption washing & drying	1224 kWh
Cord length	1.5 m
Inlet hose length	1 m
Power plug type	Type G
AC input voltage	220 - 240 V
Energy saving mode	-
Energy efficiency scale	A to G
Water consumption washing per cycle	49 L
Energy consumption washing per cycle	1.17 kWh
Water consumption washing & drying per cycle	86 L
Energy consumption washing & drying per cycle	6.12 kWh

Weight and Dimensions

Depth	580 mm
Width	600 mm
Height	850 mm
Weight	65000 g
Package width	650 mm
Package height	890 mm
Package weight	67000 g
