Candy CSOW 4963TWCE-80 User Manual

!
EN
7
2. INSTALLATION
! Remove the 2 or 4 transportation
screws (A) on the back and
remove the 2 or 4 flat washers,
rubber bungs and plastic spacer
tubes (B) as illustrated in figure 1.
! If the washing machine is built-in,
unscrew the 3 or 4 transportation
screws (A) and remove the 3 or 4
flat washers, rubber bungs and
plastic spacer tubes (B).
! During the removal of the screws
occasionally spacer tubes fall
inside the product, these can be
remove by tilting the product forward
and recovering them from the floor or
inside the base of the machine.
! Cover the open transportation screw
holes with the 2 or 4 plastic caps
included in the instruction bag.
! Place the corrugated plastic sheet,
found on top of the appliance during
the unpacking process, into the base
of the appliance as shown in figure 2
(according to the model, consider
version A, B or C).
A
A
A
A
B
B
B
B
1
3
2
1
3
1
2
A
C
B
2
WARNING:
keep packaging materials
away from children.
In some models this operation
will not be necessary, because
the corrugated plastic sheet
will be already placed on the
bottom of the appliance.

Candy CSOW 4963TWCE-80 Specifications

General

Door color	Chrome
Door hinge	Left
Motor type	Brush
Water fill	Cold
Display type	LED
Loading type	Front-load
Certification	Woolmark
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Drying system	Condensation
Drying capacity	6 kg
Washing capacity	9 kg
Delay start (max)	24 h
Residual moisture	53 %
Spin-drying class	B
Cycle time washing	228 min
Maximum spin speed	1400 RPM
Noise level (spin)	81 dB
Noise level (wash)	60 dB
Noise level (drying)	61 dB
Number of drying programs	3
Number of washing programs	14
Cycle time washing & drying	470 min
Cycle time (quick washing program)	14 min
Washing class	A
Country of origin	China
Annual water consumption washing	13600 L
Annual energy consumption washing	234 kWh
Annual water consumption washing & drying	27000 L
Annual energy consumption washing & drying	1224 kWh
Cord length	1.5 m
Inlet hose length	1 m
Power plug type	Type G
AC input voltage	220 - 240 V
Energy saving mode	-
Energy efficiency scale	A to G
Water consumption washing per cycle	49 L
Energy consumption washing per cycle	1.17 kWh
Water consumption washing & drying per cycle	86 L
Energy consumption washing & drying per cycle	6.12 kWh

Weight and Dimensions

Depth	580 mm
Width	600 mm
Height	850 mm
Weight	65000 g
Package width	650 mm
Package height	890 mm
Package weight	67000 g
