Candy CSOW 4963TWCE-80 User Manual

!
8
! Connect the water hose to the water
supply tap (fig. 3) only using the hose
supplied with the appliance (do not
reuse old hose-sets).
! SOME MODELS may include one or
more of the following features:
! HOT&COLD (fig. 4):
water mains connection settings with hot
and cold water for higher energy savings.
Connect the grey tube to the cold water
tap and the red one to the hot water
tap. The machine can be connected to
the cold water tap only: in this case, some
programs may start a few minutes later.
! AQUASTOP (fig. 5):
a device located on the supply tube that
stops water flow if the tube deteriorates;
in this case, a red mark will appear in the
window “A” and the tube must be
replaced. To unscrew the nut, press the
one-way lock device "B".
! AQUAPROTECT – SUPPLY TUBE WITH
GUARD (fig. 6):
Should water leak from the primary
internal tube "A", the transparent
containment sheath "B" will contain water
to permit the washing cycle to complete.
At the end of the cycle, contact the
Customer Service Centre to replace the
supply tube.
3
1
4
B
A
5
B
A
6
Hydraulic connections

Candy CSOW 4963TWCE-80 Specifications

General

Door color	Chrome
Door hinge	Left
Motor type	Brush
Water fill	Cold
Display type	LED
Loading type	Front-load
Certification	Woolmark
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Drying system	Condensation
Drying capacity	6 kg
Washing capacity	9 kg
Delay start (max)	24 h
Residual moisture	53 %
Spin-drying class	B
Cycle time washing	228 min
Maximum spin speed	1400 RPM
Noise level (spin)	81 dB
Noise level (wash)	60 dB
Noise level (drying)	61 dB
Number of drying programs	3
Number of washing programs	14
Cycle time washing & drying	470 min
Cycle time (quick washing program)	14 min
Washing class	A
Country of origin	China
Annual water consumption washing	13600 L
Annual energy consumption washing	234 kWh
Annual water consumption washing & drying	27000 L
Annual energy consumption washing & drying	1224 kWh
Cord length	1.5 m
Inlet hose length	1 m
Power plug type	Type G
AC input voltage	220 - 240 V
Energy saving mode	-
Energy efficiency scale	A to G
Water consumption washing per cycle	49 L
Energy consumption washing per cycle	1.17 kWh
Water consumption washing & drying per cycle	86 L
Energy consumption washing & drying per cycle	6.12 kWh

Weight and Dimensions

Depth	580 mm
Width	600 mm
Height	850 mm
Weight	65000 g
Package width	650 mm
Package height	890 mm
Package weight	67000 g
