Candy CSOW 4963TWCE-80 User Manual

!
EN
9
! The washing machine should be installed in
its final position such that the water fill hose
is not kinked or trapped. The corrugated
drain hose should be inserted into suitable
drain pipe of between 50 cm and 85 cm
height above the floor using the curved drain
hose support. If an under sink connection is
used the drain hose must be routed above
the sink overfill opening to prevent back
siphoning. Care must be taken to avoid
kinking or trapping the drain hose (fig. 7).
! Level the appliance using the feet as
illustrated in figure 8:
a. turn the nut clockwise to release the
screw;
b. rotate the foot to raise or lower it until it
touches to the floor;
c. lock the foot, screwing in the nut, until it
tightens against to the bottom of the
washing machine.
! Plug in the appliance.
min 50 cm
max 85 cm
+2,6 mt
max
max 100 cm
min 4 cm
7
* ACCESSORY SOLD SEPARATELY
A
B
C
8
Setting
WARNING:
contact the Customer Service Centre
should the power cord need
replacement.
Installation faults are not covered by
the manufacturers warranty.

Candy CSOW 4963TWCE-80 Specifications

General

Door color	Chrome
Door hinge	Left
Motor type	Brush
Water fill	Cold
Display type	LED
Loading type	Front-load
Certification	Woolmark
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Drying system	Condensation
Drying capacity	6 kg
Washing capacity	9 kg
Delay start (max)	24 h
Residual moisture	53 %
Spin-drying class	B
Cycle time washing	228 min
Maximum spin speed	1400 RPM
Noise level (spin)	81 dB
Noise level (wash)	60 dB
Noise level (drying)	61 dB
Number of drying programs	3
Number of washing programs	14
Cycle time washing & drying	470 min
Cycle time (quick washing program)	14 min
Washing class	A
Country of origin	China
Annual water consumption washing	13600 L
Annual energy consumption washing	234 kWh
Annual water consumption washing & drying	27000 L
Annual energy consumption washing & drying	1224 kWh
Cord length	1.5 m
Inlet hose length	1 m
Power plug type	Type G
AC input voltage	220 - 240 V
Energy saving mode	-
Energy efficiency scale	A to G
Water consumption washing per cycle	49 L
Energy consumption washing per cycle	1.17 kWh
Water consumption washing & drying per cycle	86 L
Energy consumption washing & drying per cycle	6.12 kWh

Weight and Dimensions

Depth	580 mm
Width	600 mm
Height	850 mm
Weight	65000 g
Package width	650 mm
Package height	890 mm
Package weight	67000 g
