Candy CSOW 4963TWCE-80 User Manual

!
18
! Press the START/PAUSE button again to
re-start the programme from the point it
had been paused at.
CANCELLING THE SET PROGRAMME
! To cancel the programme, set the
selector to the OFF position.
! Wait until the DOOR LOCKED light has
gone out before opening the door.
! This button allows you to pre-programme
the wash cycle to delay the start of the
cycle for up to 24 hours.
! To delay the start use the following
procedure:
- Select the required programme.
- Press the button once to activate the
delay start and then press it again (or
hold it) to set the desired delay. The
delay increases each time the button is
pressed up to 24 hours, at which point
pressing the button again will reset the
delay start to zero.
- Confirm by pressing the START/PAUSE
button. The delay countdown will begin
and when it has finished the programme
will start automatically.
! It is possible to cancel the delay start by
turning the programme selector to OFF.
If there is a break in the power supply
whilst the machine is operating, when
the power is restored, the machine will
restart from the beginning of the phase it
was in when the power was lost.
This button allows you:
- Automatic washing/drying cycle
After the selection of washing programme
according to laundry type, select a degree
of dryness by pressing this button. At the
end of the washing programme, the
selected drying cycle will start automatically.
If a washing programme is not compatible
with automatic drying is selected, this
function will not be activated.
- To only perform a drying cycle
Select the desired drying programme
in conjunction with your fabrics, by
pressing this button it is possible to
select a degree of dryness that is
different to the default one (except for
the wool drying programme).
When the display shows that the
programme is finished and the DOOR
LOCKED indicator light has gone out, the
door can be opened.
IN SOME MODELS, this button is combined
with the STEAM function :
- STEAM
! By this option you can add a specific
steam treatment to some washing cycles
(see programme table).
For safety reasons, in some wash
cycle phases, the door can be opened
only if the level of the water is below
its lower edge and if the temperature
is less than 45°C. If these conditions
are met, wait for the DOOR LOCKED
light to switch off before opening the
door.
DELAY START button
The option buttons should be selected
before pressing the START/PAUSE
button. If an option is selected that is
not compatible with the selected
programme then the option indicator
light first flashes and then goes off.
DRYING SELECTION/STEAM
button
If you exceed the maximum dryable load
of laundry indicated in the programme
table, the laundry may not be dried
satisfactory.

Candy CSOW 4963TWCE-80 Specifications

General

Door color	Chrome
Door hinge	Left
Motor type	Brush
Water fill	Cold
Display type	LED
Loading type	Front-load
Certification	Woolmark
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Drying system	Condensation
Drying capacity	6 kg
Washing capacity	9 kg
Delay start (max)	24 h
Residual moisture	53 %
Spin-drying class	B
Cycle time washing	228 min
Maximum spin speed	1400 RPM
Noise level (spin)	81 dB
Noise level (wash)	60 dB
Noise level (drying)	61 dB
Number of drying programs	3
Number of washing programs	14
Cycle time washing & drying	470 min
Cycle time (quick washing program)	14 min
Washing class	A
Country of origin	China
Annual water consumption washing	13600 L
Annual energy consumption washing	234 kWh
Annual water consumption washing & drying	27000 L
Annual energy consumption washing & drying	1224 kWh
Cord length	1.5 m
Inlet hose length	1 m
Power plug type	Type G
AC input voltage	220 - 240 V
Energy saving mode	-
Energy efficiency scale	A to G
Water consumption washing per cycle	49 L
Energy consumption washing per cycle	1.17 kWh
Water consumption washing & drying per cycle	86 L
Energy consumption washing & drying per cycle	6.12 kWh

Weight and Dimensions

Depth	580 mm
Width	600 mm
Height	850 mm
Weight	65000 g
Package width	650 mm
Package height	890 mm
Package weight	67000 g
