10
Front Brake and Cable Guide Installation
Front Brake and Cable Guide Screw/
Cover Installation:
Install brake caliper according to the
brake manufacturer’s instructions.
Route the front disc brake hose or
cable housing on the inside of the
lower fork leg through the disc brake
housing guide.
WARNING: Ensure that all bolts are
tightened to the correct torque and
that fork movement is not restricted by
improper assembly when the suspension
is fully compressed or extended.
Torque to 1Nm Max
To Next Page
