11
1. Remove D-LOC axle from fork
by opening the cam lever, then
moving the axle lock latch to the
“unlocked” position and slide the
axle out of the fork.
2. Install front wheel into the dropouts
and insert the D-LOC axle with text
“THIS SIDE UP” facing towards
the head tube through the dropout.
Use an anti seize or grease on axle
shaft to promote longevity of axle
function.
D-Loc Axle Installation
THIS SIDE UP
1.
2.
Cam Lever
Latch Lock
