12
3. Lock the D-LOC axle lock latch.
4. Use the tension adjuster to
adjust the axle’s clamp strength
and close axle lever to complete
wheel installation.
WARNING: An improperly
tensioned axle, a lever not
completely engaged or a lever not
positioned in the upward closed
position could result in disengagement
of the axle and possibly causing
serious injury or death.
D-Loc Axle Installation
3.
4.
Tension Adjuster
