20
Internal Travel Adjustment
Cane Creek Helm fork travel is preset
from the factory, but travel can be
changed internally in 10mm increments
if desired. Two travel reducers are
included with every HELM fork.
Tools required:
• 13mm Wrench
• 18mm Wrench
• 22mm Wrench
• Travel Reducers
WARNING: READ ALL STEPS
BEFORE PERFORMING TRAVEL
ADJUSTMENT Follow these steps
carefully to avoid foul assembly,
warranty void, or serious injury. If you
do not feel confident performing this
procedure, contact a professional bike
mechanic or a Cane Creek authorized
Service Center. *For a detailed step by
step video of this process, visit http://
www.canecreek.com/tech-center/sus-
pension/service-videos*
1. Remove air cap from top of fork,
remove charge air cap off bottom of
fork, unthread air charge button on
bottom of fork.
1.
Travel Reducers
