Cannondale C440 - Footpegs

22
Footpegs
6
5
3
2
4
7
1
*
* 2 5000136 X X X X BHCS, M10X30, NYLKZNC USE W/ KICKSTAND
7 2 5001264 X X BHCS, M10X25, NYLKZNC
6 1 5001919 FOOTPEG BRACKET
5 1 5000526 FOOTPEG, LEFT
4 1 5000713 FLAT WASHER, M8
3 1 5000400 COTTER PIN, 2.5X20
2 1 5000985 FOOTPEG SPRING, LEFT
1 1 5000986 FOOTPEG PIVOT PIN
XSEEAERC
NOTES
MODEL
LEFT FOOTPEG PARTS LIST
ITEM
NO
QTY
REQD
DEA LER PA RT
NUMBER
DESCRIPTION
1
7
6
5
2
4
3
7 2 5001264 BHCS, M10X25, NYLKZNC
6 1 5001919 FOOTPEG BRACKET
5 1 5002286 FOOTPEG, RIGHT
4 1 5000713 FLAT WASHER, M8
3 1 5000400 COTTER PIN, 2.5X20
2 1 5000984 FOOTPEG SPRING, RIGHT
1 1 5000986 FOOTPEG PIVOT PIN
XSEEAERC
RIGHT FOOTPEG PARTS LIST
ITEM
NO
QTY
REQD
DEA LER PA RT
NUMBER
DESCRIPTION NOTES
MODEL
