Cannondale C440 - Fuel Tank

33
Fuel Tank
4
3
1
2
5
6
11
13
14
7
10
8
9
12
9
*
*
14 2 5000799 TOP-HAT WASHER, FUEL TANK TAB
13 2 5000765 TOP-HAT WASHER
12 4 5000192 FLAT WASHER, M6
11 2 5000862 FLNG HD BLT, M6X40 mm
10 2 5000802 GROMMET, FUEL TANK
9 3 5000137 FHCS, M6X16 ZINC
8 1 5002398 SEAT CATCH
7 1 5000175 FUEL TANK BREATHER HOSE
6 1 5000873 FUEL TANK CAP GASKET
5 1 5000169-01 FUEL TANK CAP
4 1 5001778 FUEL PICKUP FILTER INCLUDED IN FUEL TANK
* 1 5002270 X X X FUEL PICKUP TUBE INCLUDED IN FUEL TA NK
3 1 5002417 X X FUEL PICKUP TUBE INCLUDED IN FUEL TANK
2 2 5002140-02 FUEL TANK FEMALE QUICK CONNECT INCLUDED IN FUEL TANK
* 1 351-5002074 X X X FUEL TANK
1 1 351-5002244 X X FUEL TANK
XSEEAERC
FUEL TANK PARTS LIST
ITEM
NO
QTY
REQD
DEA LER PA RT
NUMBER
DESCRIPTION NOTES
MODEL
