Cannondale C440 - Front Fork Parts List

8
Front Fork List
13 2 5000548 FORK OUTER TUBE BUSHING SLEEVE
12 4 5000547 FORK OUTER TUBE BUSHING
11 2 5000561 FORK OUTER TUBE BUSHING CIRCLIP
10 2 5000005 FORK OUTER TUBE
9 2 5000559 FORK OUTER TUBE DECAL
8 2 SEE TABLE FORK SPRING
7 2 5000553 FORK SPRING WASHER
6 2 5000552 FORK SPRING SPACER
5 2 5000546 FORK OUTER TUBE CAP O-RING
4 2 5000545 FORK OUTER TUBE CAP
3 2 5000551 FORK AIR BLEED SCREW O-RING
2 2 5000550 FORK AIR BLEED SCREW
1 2 5000549 FORK OUTER TUBE CAP NUT
XSEEAERC
FRONT FORK PARTS LIST
ITEM
NO
QTY
REQD
DEA LER PA RT
NUMBER
DESCRIPTION NOTES
MODEL
5002526 X FORK GUARD SET, MOTARD - SILVER
5002055 X X X X X FORK GUARD SET - SILVER
5000018 FORK GUARD SET - BLACK
5001222 FORK GUARD SET - WHITE
5000013 FORK SPRING - 4.5 N/mm OPTIONAL
5000014 FORK SPRING - 4.7 N/mm STANDARD
5000015 FORK SPRING - 4.9 N/mm OPTIONAL
* 1 5002617 X FRONT FORK SET, CR
* 1 5002619 X FRONT FORK SET, ER
* 1 5002621 X FRONT FORK SET, EA
* 1 5002621 X FRONT FORK SET, E
* 1 5002523 X FRONT FORK SET, S
59 1 5002600 X FRONT FORK SET, X
58 AR 5000572 OHLINS FORK FLUID, 1LITER
57 AR 5001526 FORK SERVICE KIT
56 1 5000568 FORK INNER TUBE ASSY-RIGHT
55 2 5000608 COMPRESSION ADJUSTER ASSY.
54 2 5000607 COMPRESSION ADJUSTER O-RING
53 2 5000610 COMPRESSION SHIM SET
52 2 5000611 FORK COMPRESSION PISTON
51 2 5000606 FORK COMPRESSION PISTON O-RING
50 2 5000603 COMPRESSION PISTON SHIM
49 2 5000604 COMPRESSION PISTON WAVE WSHR
48 4 5000558 FRONT WHEEL AXLE PINCH BOLT
47 1 5000567 FORK INNER TUBE ASSY-LEFT
46 6 5000556 FORK GUARD BOLT
45 1 SEE TABLE FORK GUARD SET
44 2 5000518 FORK INNER TUBE BUSHING
43 2 5000565 DAMPING CARTRIDGE TUBE
42 4 5000080 LOCKNUT
41 4 5000601 WASHER
40 2 5000600 MID VALVE SHIM SET
39 2 5000598 FORK REBOUND PISTON RING
38 2 5000597 FORK REBOUND PISTON
37 2 5000594 REBOUND SHIM SET
36 2 5000593 REBOUND ADJUSTER BODY
35 2 5000592 REBOUND ADJNEEDLE SPRING
34 2 5000591 REBOUND ADJ NEEDLE
33 2 5000590 REBOUND ADJ NEEDLE O-RING
32 2 5000587 FORK TOP OUT SPRING
31 2 5000589 FORK DAMPER ROD
30 2 5000586 FORK TOP OUT SPRING WASHER
29 2 5000585 FORK DAMPER ROD BUSHING
28 2 5000584 FORK DA MPER ROD SLEEVE O-RING
27 2 5000583 FORK DAMPER ROD SLEEVE
26 2 5000582 DAMPING CARTRIDGE TUBE CAP
25 2 5000581 DAMPER ROD CIRCLIP
24 2 5000580 HY DRAULIC STOP COLLAR CIRCLIP
23 2 5000579 FORK HYDRAULIC STOP
22 2 5000578 FORK HYDRAULIC STOP COLLAR
21 2 5000577 FORK SPRING GUIDE
20 2 5000575 REBOUND ADJUSTER ASSY.
19 2 5000576 REBOUND ADJUSTER O-RING
18 2 5000574 FORK REBOUND ADJUSTER ROD
17 2 5000564 FORK WIPER
16 2 5000560 FORK SEAL RETAINING CIRCLIP
15 2 5000563 FORK SEAL
14 2 5000562 FORK SEAL RETAINING WASHER
ADDITIONAL PARTS TABLE
