5
5002540 WEIGHT, WHEEL BALANCE Strip of 12, 1/4 oz w eights
5000339 SPROCKET, REAR, 49 T
5000349 SPROCKET, REAR, 51 T
5000357 SPROCKET, REAR, 52 T
151-5002499 REAR WHEEL ASSEMBLY, MOTARD
151-5002085 REAR WHEEL ASSEMBLY, 18"
151-5000069 REAR WHEEL ASSEMBLY, 19"
18 2 5002199 DUST CAP
* 18 5002502 X SPOKE, REAR, OUTSIDE, 4.0X175.0 mm INCLUDED IN RR WHL ASSYS
* 18 5001873 X X X X SPOKE, REAR, OUTSIDE, 18" WHEEL INCLUDED IN RR WHL ASSYS
17 18 5000075 X SPOKE, REAR, OUTSIDE, 19" WHEEL INCLUDED IN RR WHL ASSYS
* 18 5002503 X SPOKE, REAR, INSIDE, 4.0X181.0 mm INCLUDED IN RR WHL ASSYS
* 18 5002287 X X X X SPOKE, REAR, INSIDE, 18" WHEEL INCLUDED IN RR WHL ASSYS
16 18 5000797 X SPOKE, REAR, INSIDE, 19" WHEEL INCLUDED IN RR WHL ASSYS
15 36 5001624 NIPPLE, REAR INCLUDED IN RR WHL ASSYS
14 6 5000713 FLAT WASHER, M8
13 6 5000140 LOCKNUT, M8
12 6 5000393 FHCS, M8X28 mm, ZINC
* 1 5002521 X SPROCKET, REAR, 45T
11 1 5000117 X X X X X SPROCKET, REAR, 50 T
* 1 6000315 X X X X MASTER LINK, O-RING
10 1 5001847 X X MASTER LINK
* 1 5002522 X CHAIN, DRIVE, 112 LINKS
* 1 5001798 X X X X CHAIN, DRIVE, 114 LINKS, O-RING
9 1 5001601 X CHAIN, DRIVE, 114 LINKS
8 4 5000138 FHCS, M8X16, NYLK, ZINC
7 1 5000090 ROTOR, REAR
* 1 5002505 X RIM, REAR, 17X4.50", BLK INCLUDED IN RR WHL ASSY
* 1 5001886 X X X X WHEEL RIM, REAR, 18" INCLUDED IN RR WHL ASSY
6 1 5000076 X WHEEL RIM, REAR, 19" INCLUDED IN RR WHL ASSY
5 1 5000077 RIM LOCK, REAR
* 1 5002510 X RIM STRIP, 17"
* 1 5002130 X X X X RIM STRIP, REAR
4 1 5000078 X RIM STRIP, REAR
* 1 5002508 X TUBE, 120/70-17
* 1 5002131 X X X X TUBE, REAR
3 1 5000079 X TUBE, REAR
* 1 5002507 X TIRE, REAR, 150/60-17
* 1 5002132 X X X X TIRE, REAR, 18"
2 1 5000080 X TIRE, REAR, 19"
1 1 SEE REAR HUB REAR HUB ASSEMBLY INCLUDED IN RR WHL ASSYS
XSEEAERC
ADDITIONAL PARTS TABLE
REAR WHEEL PARTS LIST
ITEM
NO
QTY
REQD
DEA LER PA RT
NUMBER
DESCRIPTION NOTES
MODEL
