32
Airbox
11
1
2
10
9
4
3
8
12
7
5
6
16
13
14
15
14
17
18
18 1 5000793 HOSE CLAMP, 5.6mm - 16mm
17 1 5002331 HOSE, BREATHER, FRAME TO ARIBOX
16 1 5001922 VACUUM HOSE, 5/32" ID 265 mm TO PRESSURE REGULATOR
15 1 5001595 VACUUM HOSE, 5/32" ID 609 mm TO ECU
14 2 5000962 VACUUM HOSE, 5/32" ID 185 mm (1) TO ENGINE & (1) TO AIRBOX
13 1 5002529 4-WAY FITTING, VACUUM HOSE
12
1
5000487 O-RING, 2-012
11 1 5000403 AIR TEMPERATURE SENSOR
10
1
5001149 CLAMP, BAND
9 2 5002293 TOPHAT, AIRBOX
8 2 5000178 GROMMET, 3/8 ID
7 2 5000350 FHB, M6X30, mm
6 1 5002152 AIR FILTER CLIP
5 1 5002150 AIR FILTER
4 6 5001238 RIVET AB4-6CLD INCLUDED IN 603-5002149-03
3 2 5001239 INTAKE END RETAINING RING INCLUDED IN 603-5002149-03
2 1 5002138 AIR FUNNEL INCLUDED IN 603-5002149-03
1 1 603-5002149-03 AIRBOX
XSEEAERC
AIRBOX PARTS LIST
ITEM
NO
QTY
REQD
DEA LER PA RT
NUMBER
DESCRIPTION NOTES
MODEL
