Cannondale E440 - Rear Suspension Maintenance

© 2001 Cannondale Corporation - All Rights Reserved
86
Motorcycle Maintenance and Adjustment.fm
REAR SUSPENSION
NOTE :
Component shown removed for clarity
(1)
(2)
(3)
(4)
(8)
(7)
(6)
(5)
(10)
(9)
1. Body
2. Reservoir
3. Nitrogen gas hazard warning
4. Compression damping adjuster
5. Spring
6. Spring ID (Type, rate)
7. Adjuster nut
8. Lock ring
9. Rebound damping adjuster
10.Bump stop
