[Bit 6]
It is possible to choose to send out CNG signal when manual TX is set. If the document is sent manually to the
machine with [FAX/TEL AUTO SW] mode selected.
[Bit 7]
It is possible to send out CED signal when manual RX is set.
Even if manual RX is set, please choose to send out CED signal when the other party does not start transmitting
the document.
#1 SSSW
SW05 (Service Soft Switch05; Standard Feature <DIS signal> setting)
Bit Function 1 0
0 Not in use
1 Not in use
2 Not in use
3 Not in use
4 Length of Print Media indicated by DIS signal A4/B4 size Any size
5 Indication of LTR/Legal by DIS signal No Yes *
6 Sending ECM No Yes *
7 Sending ECM No Yes *
[Bit 4]
It is possible to select A4/B4 as the print media length to be indicated by DIS signal.
If the machine is to receive a banner paper-size document, be sure to select A4/B4 as the media size to receive it
dividing it into 2 pages
*When selecting A4/B4, a DIS signal notifying that the A4 or B4 recording papers are available is
sent to the transmitting machine. After receiving the DIS signal, the transmitting machine divides
the long-size document into A4 or B4 size, and then sends the document to the receiving machine.
Some models of transmitting machines may not divide a long-size document.
[Bit 6]
It is possible to select ECM TX.
If ECM TX is not set, ECM TX is disabled.
[Bit 7]
It is possible to select ECM RX.
If ECM RX is not set, ECM RX is disabled.
1-32
