3.3 Explanation of service data
SSSW (Service Soft Switch settings)
The items registered and set by each of these switches comprise 8-bit switches. The figure
below shows which numbers are assigned to which bits. Each bit has a value of either 0 or 1.
Figure 1-10 Bit Switch Display
As for service switch and default values, please refer to the service data menu.
#1 SSW
SW01(Error/Copy Management)
Bit Function 1 0
Serviceman Error Code Output Not output*
Set value is [1].
*indicates default
value.
Set value is [0].
1 Error Dump List Output Not output*
2 Not in use
3 Copy Function Prohibited Not prohibited*
4 Not in use
5 Not in use
6 Setting of Date/Time by users Prohibited Not prohibited *
7 Not in use
* Do not change default value if function is not in use.
1-29
