Canon Duplex Unit-A1 - 1.2.2 Sectional View

Chapter 1
1-2
1.2.2 Sectional View
0010-4341
F-1-2
T-1-3
[1] Feed roller 1 [5] Delivery guide
[2] Reversal tray (sub) [6] Duplex flapper
[3] Reversal tray [7] Feed roller 2
[4] Reversal flapper [8] Feed roller 3
[1]
[3]
[2]
[4]
[6]
[5]
[7]
[8]
