Canon Duplex Unit-A1 - Page 20

Chapter 2
2-2
F-2-2
T-2-2
[1] Feed roller 1 M1001: Feed motor
[2] Feed roller 2 M1002: Reversal motor
[3] Feed roller 3 SR1002: Duplex paper sensor 1
SL1001: Duplex flapper solenoid SR1003: Duplex paper sensor 2
M1002
[2]
[1]
[3]
SR1002
SR1003
M1001
SL1001
