Canon Duplex Unit-A1 - Page 22

Chapter 2
2-4
F-2-4
2) When the trailing edge of the paper reaches the reversal point (when the predetermined time lapses after the trailing edge of the paper is detected by the delivery
sensor), the reversal motor (M1002) stops.
SR1002
SR1003
Fixing
delivery
sensor
Duplex flapper
