Chapter 5
5-1
5.1 Service Error Code
5.1.1 Error Code list
0011-2139
T-5-1
5.2 Jam Codes
5.2.1 Jam Code List
0011-2363
T-5-2
Code Details
code
Explanation Countermeasure
E052 0000 Cause of faulty connection to
duplex unit: Broken line or faulty
duplex controller PCB or DC
controller PCB
- Check the connectors of the duplex controller PCB and
DC controller PCB.
- Replace the duplex controller PCB.
- Replace the DC controller PCB.
Code Name Sensor No. Description
0120 Delay jam at duplex
paper sensor 1
SR1002 The duplex paper sensor 1 does not turn on within the specified
time after the delivery sensor on the main unit side turns on.
0124 Delay jam at duplex
paper sensor 2
SR1003 The duplex paper sensor 2 does not turn on within the specified
time after the duplex reverse motor starts.
0221 Stationary jam at
duplex paper sensor 1
SR1002 - The duplex paper sensor 1 does not turn off when the specified
time has lapsed since the duplex paper sensor 2 turned on.
- The duplex paper sensor 1 does not turn off when the paper
with a longitudinal length of 280 mm reaches the standby
position (about 90 mm from the duplex paper sensor 2).
0228 Stationary jam at
duplex paper sensor 2
SR1003 The duplex paper sensor 2 does not turn off when the specified
time has lapsed since the feed motor started.
To Next Page
