Canon GL1 - Specifications

99
E
Additional Information
Specifications
GL1
Power Supply (rated): 7.2 V DC
Power Consumption (While recording with
the AF turned on):
6.7 W (Using viewfinder),
7.4 W (Using LCD screen)
Television system:
EIA standard (525 lines, 60 fields) NTSC
color signal
Video recording system:
2 rotary heads, helical scanning system
DV system (Consumer digital VCR SD
system)
Digital component recording
Audio recording system: PCM digital sound:
16 bit (48 kHz/2 ch), 12 bit (32 kHz/4 ch)
Image sensor: 3 CCD
1
/4” Pixel Shift (charge
coupled device) 270,000 pixels
(250,000 effective pixels)
Tape format: Videocassettes bearing the D
mark
Tape speed:
SP:
3
/4 ips (18.81 mm/s);
LP:
1
/2 ips (12.56 mm/s)
Maximum recording time:
SP: 80 minutes (with an 80 min. cassette);
LP: 120 minutes (with an 80 min. cassette)
Fast forward/rewind time:
Approx. 2 min. 50 sec. (with a 60 min.
cassette)
Lens: F/1.6–2.9, 20× power zoom, 4.2–84 mm
Focusing system: TTL autofocus, manual
focusing possible
Minimum focusing distance:
3
/8 inch (10 mm) on maximum wide angle;
telephoto end: 3 ft 4 in (1 m)
Maximum shutter speed:
1/15,000 sec.
Minimum illumination: 6 lx (using the auto
program)
Recommended illumination:
More than 100 lx
Filter diameter: 58 mm
Viewfinder: 0.55-inch, color LCD
(approx. 180,000 pixels)
LCD screen: 2.5 in measured diagonally
(6.4 cm), 122,000 pixels (approx.)
Microphone: Stereo electret condenser
microphone
DV Terminal: Special 4 pin connector
(conforms to IEEE 1394)
Output level:
Video terminal: ø 3.5 mm, 1 Vp-p/75 Ω
unbalanced
S-video terminal: 4 pin mini DIN, 1 Vp-p
(Y signal), 0.286 Vp-p (C signal)
Audio terminal: ø 3.5 mm
4 dBm (47 kΩ load)/3 kΩ or less, unbalanced
Input level:
Audio terminal: ø 3.5 mm (L, R)
0 dBV/47 kΩ (LINE ATT), unbalanced
–10 dBV/47 kΩ (LINE), unbalanced
Microphone terminal: ø 3.5 mm stereo mini-
jack,
–55 dBV (with 600 Ω mic) (MIC)/600 Ω
–35 dBV (with 600 Ω mic) (MIC ATT)/600 Ω
Operating temperature range:
32°–104°F (0°–40°C)
Dimensions: 4
5
/8 × 5
3
/8 × 10
3
/4 in
(117
× 135 × 272 mm)
Weight: 2 lbs 12
1
/8 oz approx. (1.25 kg)
Battery type: Rechargeable lithium ion battery
Rated voltage: 7.2 V DC
Operating temperature: 32°–104°F (0°–40°C)
Battery capacity: 1,500 mAh
Dimensions: 1
1
/2 ×
3
/4 × 2
3
/4 in
(38.2
× 20.5 × 70.5 mm)
Weight: 3
3
/8 oz (96 g)
Weight and dimensions are approximate.
Errors and omissions excepted.
Subject to change without notice.
Canon is a trademark of Canon Inc.
BP-915 Battery Pack
