Table 33 – Multi-drawer Paper Deck-B1 Consumable Parts List
Multi Drawer Paper Deck-B1 Consumable Parts List
Description
Item Number
2
Quantity
Estimated Life
(copies/prints
50
Remarks
Upper deck pickup roller-front FF5-7829-000 1 500,000 sheets
Upper deck pickup roller-rear FF5-7830-000 1 500,000 sheets
Upper deck separation roller FE3-9017-000 1 500,000 sheets
Upper deck pickup/feed roller
FF6-1975-000 1 500,000 sheets
Upper deck pickup clutch FH6-5145-000 2 4,000,000 times
Upper deck pickup roller
release solenoid
FH6-5146-000 1 4,000,000 times
Middle deck pickup roller-front
FF5-7829-000 1 500,000 sheets
Middle deck pickup roller-rear
FF5-7830-000 1 500,000 sheets
Middle deck separation roller FE3-9017-000 1 500,000 sheets
Middle deck pickup/feed roller
FF6-1975-000 1 500,000 sheets
Middle deck pickup clutch FH6-5145-000 2 4,000,000 times
Middle deck pickup roller
release solenoid
FH6-5146-000 1 4,000,000 times
Lower deck pickup roller-front FF5-7829-000 1 500,000 sheets
Lower deck pickup roller-rear
FF5-7830-000 1 500,000 sheets
Lower deck separation roller FE3-9017-000 1 500,000 sheets
Lower deck pickup/feed roller
FF6-1975-000 1 500,000 sheets
Lower deck pickup clutch FH6-5145-000 2 4,000,000 times
Lower deck pickup roller
release solenoid
FH6-5146-000 1 4,000,000 times
2 Part numbers are subject to change without notice.
50 Value is based on LTR sized paper. Estimated average values in the field, based on data from supplier.
Data is subject to change depending upon many factors including, without limitation, monthly copy
volume, environment, type of image printed and customer handling of the equipment.
Table 34 – Document Insertion Unit-M1 Consumable Parts
Document Insertion Unit-M1 Consumable Parts
Item Item Number
2
Quantity
Estimated Yield
53
(copies/prints)
Remarks
Upper tray pickup roller 4A3-3870-000 2 100,000 sheets
Upper tray separation roller 4A3-3868-000 1 100,000 sheets
Upper tray feed roller 4A3-3869-000 1 100,000 sheets
Upper tray torque limiter 4A3-3888-000 1 1,000,000 sheets
Upper tray registration clutch
4H3-0290-000 1 1,000,000 times
Lower tray pickup roller 4A3-3870-000 2 100,000 sheets
Lower tray separation roller 4A3-3868-000 1 100,000 sheets
Lower tray feed roller 4A3-3869-000 1 100,000 sheets
Lower tray torque limiter 4A3-3888-000 1 1,000,000 sheets
2 Part numbers are subject to change without notice.
53 Estimated Yield is based on LTR paper
