R. Main Unit Fixing Assembly
As an option, Canon USA has made available the Main Unit Fixing Assembly,
which consists of consumable and periodically replaced parts.
The service technician replaces the assembly when any or all of the parts
within the assembly have reached the recommended replacement interval.
The service technician would then be able to service the Main Unit Fixing
Assembly (replacing the consumable and periodically replaced parts) to
prepare it for the next time the assembly requires replacement.
Having this assembly may be beneficial to servicing dealers that would like to
build a service strategy around replacing the Main Unit Fixing Assembly
thereby providing the customer with higher uptime due to faster parts
replacement. If this is the case, Canon USA recommends having at least one
(1) Main Unit Fixing Assembly available as a replacement at the customer
site.
Table 42 – Main Unit Fixing Assembly
Main Unit Fixing Assembly
Item Item Number
2
Quantity Components imagePRESS
Estimated Life
50
(copies/prints)
Remarks
LTR
@ 50%
11”x17”
Main Unit
Fixing
Assembly
FM1-C719-000 1
Fixing Belt Unit
FM1-C721-000
C800 600,000 pages 400,000 pages
May change
depending on
the Heavy
Paper Usage
C700 500,000 pages 330,000 pages
Pressure Belt Unit
FM1-C722-000
C800 600,000 pages 400,000 pages
C700 500,000 pages 330,000 pages
Pressure Sub
Thermistor (Rear)
FK2-7870-000
C800 1,200,000 800,000
C700 1,000,000 666,667
Pressure Sub
Thermistor (Front)
FK2-7871-000
C800 1,200,000 800,000
C700 1,000,000 666,667
2 Part numbers are subject to change without notice.
50 Estimated average values in the field, based on data from supplier. Data is subject to change depending upon
many factors including, without limitation, monthly copy volume, environment, type of image printed and
customer handling of the equipment.
Canon imagePRESS C800/C700 Service Guide October 2014
Revision 2 Page 70
