Canon imagePRESS C800/C700 Service Guide
Table 35 – Finisher-AM1 /Saddle Finisher-AM2 Consumable Parts
Finisher-AM1 /Saddle Finisher-AM2 Consumable Parts
Item Item Number
2
Quantity
Estimated Yield
53
(copies/prints)
Remarks
Stapler FM2-6541-030 1 500,000 times
Finisher
Puncher Unit-BS1 FE3-1671-000 1 1,000,000 times
Finisher
Puncher Unit-BT1 FE3-1672-000 1 1,000,000 times
Finisher
Delivery Static Eliminator FC9-3038-000 1 3,000,000 pages Finisher
Stack Delivery Roller Static
Eliminator
FE3-0006-000 1 3,000,000 pages Finisher
Feed Belt FB5-9103-000 2 3,000,000 pages Finisher
Neat Paddle FL3-7459-000 4 3,000,000 pages
Finisher
Belt Roller FC6-6148-000 2 6,000,000 pages Saddle Stitcher
Saddle stapler FM4-7572-000 1 300,000 times Saddle Stitcher
Saddle Inlet Roller Static
Eliminator
FC9-1393-000 2 3,000,000 pages
Saddle Stitcher
Saddle Inlet Static Eliminator FC9-1432-000 1 3,000,000 pages
Saddle Stitcher
Saddle Disengagement Roller FL3-2010-000 2 1,000,000 pages
Saddle Stitcher
Saddle Alignment Roller FC8-7495-000 4 5,000,000 pages
Saddle Stitcher
Saddle Intermediate Static
Eliminator
FL3-2005-000 1 3,000,000 pages Saddle Stitcher
Saddle Feed Guide Lower
Static Eliminator
FC9-1394-000 3 3,000,000 pages Saddle Stitcher
2 Part numbers are subject to change without notice.
Table 36 – Paper Folding Unit-F1
Paper Folding Unit-F1 Consumable Parts List
Description
Item Number
2
Quantity
Estimated Life
(copies/prints
50
)
Remarks
Through-feed inlet antistatic
needle
FL3-3406-000 2 6,000,000 pages
Through-feed outlet antistatic
needle
FL3-3418 -000 2 6,000,000 pages
Folding front lower roller
clutch 1
FK2-4588-000 1 1,000,000 times
Folding front lower roller
clutch 2
FK2-4588-000 1 1,000,000 times
Folding/spacing solenoid FM4-4117-000 1 1,000,000 times
Through/folding branching
fapper solenoid
FM3-2307-000 1 2,000,000 times
C-fold stopper solenoid FK2-4587-000 1 3,000,000 times
C-fold tray branching
solenoid
FM3-2290-000 1 3,000,000 times
2 Part numbers are subject to change without notice.
50 Value is based on LTR sized paper. Estimated average values in the field, based on data from supplier.
Data is subject to change depending upon many factors including, without limitation, monthly copy
volume, environment, type of image printed and customer handling of the equipment.
Canon imagePRESS C800/C700 Service Guide October 2014
