Table 37 – Perfect Binder-B1 Consumable Parts
Perfect Binder-B1 Consumable Parts
Item Item Number
2
Quantity
Estimated Yield
53
(copies/prints)
Remarks
Static eliminator (Signature
delivery assembly)
4A3-2770-000 2
2,000,000 pages
4A3-3512-000 2
Switchback roller (Stacking
tray assembly)
FC9-2351-000 2 1,000,000 pages
Stack thickness volume
sensor
412-2661-000 1 50,000 times
Number of bookbindings
Gripper motor (front/rear) 4H3-0382-000 2 100,000 times
Glue vat unit 4G3-1133-000 1 2,000 hours
Corrugation roller
4G3-1167-000
4G3-1168-000
5 1,000,000 pages
Trimming blade 4Y8-3057-000 1 40,000 times
Number of trimming
operations
Trimming blade plate FM1-B633-000 1 11,000 times
Number of trimming
operations
Static eliminator (Stacking
tray assembly)
4G3-1143-000 1 2,000,000 pages
Static eliminator (Cover
transport assembly)
4A1-8890-000 2
2,000,000 pages
4A3-3510-000 1
4A3-3452-000 2
4A1-8890-000 2
Switchback roller (Cover
transport assembly)
4A3-2846-000 2 1,000,000 pages
Deodorizing filters/sheets
FC6-4242-000 3
1,000,000 sheets
4A3-3521-000 2
4Y3-0017-000 1
Trail edge retaining roller
4A3-3423-000 4
1,000,000 pages
4A3-3424-000 2
Torque diode (Stack rotation
assembly)
4F3-0589-000 1 50,000 times
Number of bookbindings
Torque limiter (Cover
transport assembly)
FL3-1552-000 1 1,000,000 times
Torque limiter (Stack rotation
assembly)
XG9-0583-000 1 50,000 times
Flapper (Stack rotation
assembly)
FL2-9852-000 1 13,000 times
Waste paper wiper plate 4F3-0592-000 1 40,000 times
Number of trimming
operations
Waste paper buffer shift
motor
4G3-2004-000 1 50,000 times Number of bookbindings
