imagePROGRAF iPF850/iPF840/iPF830 Service Guide July 2015
Page 21
J. Consumable Parts
Consumable parts are defined as those parts having a limited life that will be
reached during a customer’s specific machine operation, and should then be
replaced as needed. Examples of consumable parts include, but are not
limited to, the linear scale and carriage unit.
An estimated consumable parts list is available in the tables below to assist in
the initial parts/supplies planning. The printer usage factors (paper size, paper
quality, environment, usage application, and machine maintenance) affect the
estimated life of consumable parts. Therefore, consumable parts do not have
a warranty, and Canon USA cannot guarantee a minimum life.
Note: All consumable parts shown in the table below are for reference
purposes only, and are subject to change without notice.
Table 24 - imagePROGRAF iPF850/iPF840/iPF830 Consumable Parts List
Unit Description
Counter
Name
Part Number
2
Estimated Life
7
(A0 Size)
Waste Ink
Collection Unit
Waste Ink Box Unit (L) Wia1 QM3-4814-000 25,000 pages
Waste Ink Absorber Unit
Wia2
QL2-2822-000
25,000 pages
(6,000 pages in
continuous
borderless printing)
Wia3
Wia4
Platen Suction Fan Unit
Wia5
QM3-4827-000
25,000 pages
Platen Fan Duct Unit QM3-4816-000
Waste Ink Box Unit QM3-4828-000
Carriage
System
Carriage Unit CR1 QM4-8607-000 25,000 pages
Carriage Unit
CR2
QM4-8607-000 25,000 pages
Scale, Linear QD1-0970-000 25,000 pages
Carriage Unit CR3 QM4-8607-000 25,000 pages
Ink Supply Unit Tube Unit CR4 QM4-8549-000 25,000 pages
Multi Sensor Multi Sensor Unit CR5 QM4-8148-000 25,000 pages
Purge System
Purge Unit
PG1, 2
QM3-4847-000 25,000 pages
Waste Ink Receptacle
Unit
QM3-4912-000 25,000 pages
Non-Ejection
Detection
Head Management
Sensor Unit
Hma1 QM3-4844-000 25,000 pages
CR Motor CR Motor, DC MT1 QK1-5211-000 25,000 pages
Transportation
Feed Motor Assembly PL1 QM3-5246-000 100,000 pages
Roller, Pick-Up Pra1
QD1-1323-000
25,000 pages
Roller, Pick- Up (2nd) Prb1 25,000 pages
Mist Collection Mist Fan Unit Mi1 QM3-4846-000 50,000 pages
Cutter System Cutter CT1 QM3-4873-000 100,000 pages
2 Part numbers are subject to change without notice.
7 Based on Coated paper, Photo Illustration, Standard mode, Image Duty: 12.5% each color x 4 (total 50% duty). The estimated
life is subject to change depending upon many factors including, without limitation the print mode, operating condition, type of
image printed and customer handling of the equipment.
