Using this printer , you can print ne lines and text clearly and sharply . It’ s easy to produce highly precise
drawings from CAD applications.
For instructions on CAD printing, refer to the following topics, as appropriate for your computer and operating
system.
• Printing Line Drawings and T ext (Windows) (→P .287)
• Printing Line Drawings and T ext (Mac OS X) (→P .284)
• Printing Line Drawings and T ext (Mac OS 9) (→P .250)
Printing Line Drawings and T ext (Mac OS 9)
This topic describes how to print line drawings based on the following example.
• Document: CAD drawing
• Page size: A3 (297.0 × 420.0 mm [1 1.7 × 16.5 in])
• Paper: Roll
• Paper type: Plain Paper
• Roll paper width: A2/A3 roll (420.0 mm [16.5 in])
1. Select the printer in Chooser .
2. Choose Page Setup from the application menu to display the Page Attribute dialog box.
3. In the A Page Size list, click the size of the original. In this case, click ISO A3 .
4. Click I OK to close the dialog box.
5. Choose Print in the application menu.
