Clearing Staple Jams
2-68
2
Troubleshooting
Staple Finisher-D1/Booklet Finisher-D1 (Optional)
If a staple jam occurs in the stapler unit of the Staple Finisher-D1 or Booklet Finisher-D1, or inside the saddle stitcher unit of
the Booklet Finisher-D1, a screen similar to the one shown below appears on the touch panel display. Check the location of the
staple jam, and follow the procedure described below, and the procedure that appears on the touch panel display, to remove any
jammed staples.
Stapler Unit
Saddle Stitcher Unit
Stapler Unit
1
Remove the paper waiting to be stapled from the delivery tray.
To Next Page
