C an o n imageRUNNER ADVANCE DX C3800 Series Service Guide
imageRUNNER ADVANCE DX C3800 Series Service Guide March 2023
Revision 4 Page 72
3. Toner Bottle Counters
The imageRUNNER ADVANCE DX C3800 Series machines also have a
Toner Bottle Counter that counts up after the machines recognize that a
new toner bottle has been inserted. The toner bottle is installed to provide
support for billing customers who order and consume a lot of toner. Toner
units that are shipped can be compared against toner bottles actually
installed in the machine.
Table 24 – Toner Bottle Counters
Counter Number
Premature Yellow: 065
Premature Magenta: 066
Premature Cyan: 067
New Black: 071
New Yellow: 072
New Magenta: 073
New Cyan: 074
Premature + New Black: 081
Premature + New Yellow: 082
Premature + New Magenta: 083
Premature + New Cyan: 084
Unidentified Black: 181
Unidentified Yellow: 182
Unidentified Magenta: 183
Description
Counts how many toner bottles are consumed throughout
the life of the machine.
Service Mode
COPIER > OPTION > USER > TNRB-SW (Level 2)
Display on the Counter Check
Screen
1: Replaced New counter (70s) is displayed
2: Not used
3: Replaced New counter and Unidentified counter
(70s, 180s)
4:
Premature Replacement counter, Replaced New
counter, & Unidentified counter (60s, 70s, 180s)
Remarks
Backed up three times
42 The counter is not advanced under these conditions after replacing the DC Controller PCB:
- The DC Controller was replaced when the power was OFF, and a new toner bottle was installed before the
power was turned ON.
- The DC Controller was replaced when the power was OFF, the power was turned back ON, and then a new
toner bottle was installed (old bottle was already removed or the front door was open).
