Canon iP2000 - Parts List

11
Parts List
Key Part Number Rank Q'ty Description Remark
Common
parts
QY6-0054-000 K 1 PRINT HEAD B
1 QC1-5041-000 J 1 PAPER SUPPORT TRAY
2 QC1-5040-000 J 1 PAPER SUPPORT
3 QM2-1674-000 J 1 UPPER COVER UNIT
4 QC1-5038-000 J 1 SIDE COVER L
5 QC1-5039-000 J 1 SIDE COVER R
6 QC1-5055-000 J 1 PANEL COVER R
7 QC1-5056-000 J 1 PANEL COVER L
8 QC1-5037-000 J 1 ACCESS COVER
9 QM2-1735-000 I 1 LOGIC BOARD ASS’Y
10 QC1-5042-000 J 1 OUTPUT TRAY
11 QC1-5043-000 J 1 EXTENTION OUTPUT TRAY
12 QC1-5052-000 J 1 OUTPUT TRAY HOLDER
13 QM2-1672-000 J 1 BASE COVER UNIT
14 QM2-1673-000 J 1 FRONT COVER
QK1-0927-000 I 1 AC ADAPTER: 100/120V 50/60HZ LV
15
QK1-0930-000 N 1 AC ADAPTER: 220/240V 50/60HZ HV (EUR/ASIA/AU/KR/HK/GB/EUM)
QC1-5005-000 J 1 EMBLEM (E) B
16
QC1-5009-000 J 1 EMBLEM (J) B
17 QC1-5111-000 J 1 PIXMA LABEL (E)
18 QC1-5104-000 I 1 TIMING SLIT STRIP FILM B
19 QC1-5106-000 I 1 TIMING SLIT STRIP FILM SPRING
20 QC1-5080-000 J 1 PAPER FEED GUIDE COVER
21 QM2-1678-000 I 1 CAP UNIT
22 QC1-5024-000 I 1 BLADE LOCK LEVER
23 QM2-1676-000 I 1 BLADE UNIT
24 QC1-5022-000 I 2 INK ABSORBER1
25 QC1-5105-000 I 2 INK ABSORBER2
26 QC1-5023-000 I 1 INK ABSORBER3
27 QC1-5021-000 I 1 INK ABSORBER4
28 QC1-5020-000 I 1 INK ABSORBER5
29 QC1-5007-000 I 1 PLATEN ABSORBER
S1 XA9-1493-000 G SCREW, TP M3x8 FOR UPPER CASE UNIT
FOR PRINT UNIT
A
S2 XB6-7300-805 G SCREW, TP BH3x8 FOR PRINT UNIT
FOR AC ADAPTER
FOR BASE COVER UNIT
S3 XB1-7300-605 G SCREW, MACHINE WASHER HEAD M3x6
FOR LOGIC BOARD ASS’Y
A
Power cables:
QH2-2720-000 S 1 CORD, POWER 120V (LAM-LV) A
QH2-2724-000 S 1 CORD, POWER 100V-120V (JP) B
QH2-2725-000 S 1 CORD, POWER 100V-120V A
QH2-2726-000 S 1 CORD, POWER 220V-240V A
QH2-2727-000 S 1 CORD, POWER 220V-240V (AU) A
WT3-5156-000 S 1 CORD, POWER 220V-240V (GB, HK) A
WT3-5160-000 S 1 CORD, POWER 220V-240V (KR) A
WT3-5182-000 S 1 CORD, POWER 220V-240V (CHN) A
A: In common with the iP1500 and iP1000
B: In common with the iP1500
