System Configuration and Parts
1-15
Before You Start Using This Machine
1
Internal View
a Front Cover
b Paper Drawer’s Left Cover
c Left Cover
d Fixing Unit
e Scanning Area
f Underside of the Feeder/Platen Cover
g Platen Glass
h Toner Cartridge
ab
c
d
e
f
g
h
The optional Fax Panel-A1 (with Super G3 FAX Board-T1), Feeder (DADF-P1),
Finisher-U1, Additional Finisher Tray-C1, and Cassette Feeding Module-J1 are attached
