Re-connect the cables.
(5) Scratches or damages to the carriage slit
film:
Replace the timing slit strip film.
(6) Black debris around the carriage rail or
pressure roller:
Replace the carriage unit.
3 times Line feed error [6000] (1) Opening and closing of the paper output
tray:
Remove obstacles from around the
paper output tray so that the tray
opens and closes properly.
(2) Smearing or scratches on the LF / EJ
slit film:
Clean the LF / EJ slit film using
lint-free paper.
(3) Foreign material in the LF drive:
Remove foreign material.
(4) Cable connection
Re-connect the cables.
If any damage or breakage of the
cable is found, replace the cable.
(5) LF lock arm spring:
Attach the spring properly.
- Timing slit disk feed
film
- Timing slit disk eject
film
- Timing sensor unit
- Paper feed roller unit
- Logic board ass'y
- Paper feed motor
4 times Purge cam sensor
error
[5C00] (1) Foreign material around the purge drive
system unit:
Remove foreign material.
(2) Cable connection:
- LF encoder cable
- PE sensor cable
- Paper feed motor harness ass'y
Re-connect the cable.
(3) Strange sound at power-on:
Replace the purge drive system unit.
- Purge drive system
unit
- Logic board ass'y
5 times ASF (cam) sensor
error
[5700] (1) Cable connection:
- PE sensor cable, etc.
Re-connect the cable.
- ASF unit
- PE sensor board
ass'y
- Logic board ass'y
6 times Internal temperature
error
[5400] (1) Cable connection:
- Between the spur unit and the logic
board, J703 connector, etc.
Re-connect the cable.
- Spur unit
- Logic board ass'y
- Print head
7 times Ink absorber full [5B00]
[5B01]
(1) Ink absorber condition:
Replace the ink absorber, and reset
the ink absorber counter value in the
EEPROM.
- Absorber kit
To Next Page
