Charging the Battery
Use the included charger to charge the battery. Be sure to charge the battery
as it is not charged at the time of purchase.
Remove the cover.
Insert the battery.
● Align the S marks on the battery and
charger, then insert the battery by sliding it
in and down .
Charge the battery.
● For CB-2LY: Flip out the plug and plug
the charger into a power outlet .
● For CB-2LYE: Plug the power cord into
the charger, then plug the other end into a
power outlet.
X The charge lamp lights red and charging
starts.
● The charge lamp will light green when
charging has finished. Charging takes
approx. 1 hour and 55 minutes.
Remove the battery.
● Unplug the battery charger from the power
outlet, then remove the battery by sliding it
in and up .
To protect the battery and prolong its life, do not charge it for longer than
24 hours continuously.
