4
Under low-light or low-contrast conditions, the built-in AF-assist beam
will be emitted automatically to make it eaasier to autofocus. The ST-
E2’s AF-assist beam is compatible with the AF points of almost all EOS
cameras. The AF-assist beam is compatible with 28mm and longer
lenses. The effective range is shown below.
Nomenclature
About the AF-Assist Beam
Position Effective Range (m / ft)
Center 0.6 - 10 / 2 - 32.8
Periphery 0.6 - 5 / 2 - 16.4
Mounting foot’s
lock lever
Mounting foot
Contacts
Locking pin
Transmitter
F-assist beam
emitter
ST-E2_E.fm Page 4 Tuesday, May 9, 2006 2:25 PM
