Network Settings Items
4-3
Appendix
4
802.1X/EAP Settings
Root CA Certificate Detailed root CA certificate information
(issuer/validation period)
Not Installed
CRL Detailed certificate revocation list
information (issuer/validation period)
Not Installed
Erase CRL Erase Erase
User Name Name of user to receive authentication
(64 characters maximum)
(NULL)
EAP Type TTLS/PEAP (802.1X Password)/TLS
(WLAN Card Certificate)
TLS (WLAN Card
Certificate)
802.1X Password Password of user to receive
authentication (64 characters maximum)
(NULL)
TTLS/PEAP Inner
Protocol
MSCHAPv2/PAP/GTC
MSCHAPv2
MSCHAPv2 Password Allow Change/Reject Change Reject Change
MSCHAPv2 New
Password
Password to use when a password
change request is received from the
server for user authentication using
MS-CHAPv2 (64 characters maximum)
(NULL)
WLAN Card Certificate Wireless LAN card certificate information
(issuer/validation period)
Not Installed
WLAN Card Private Key Set/Not Installed Not Installed
Private Key Password Password for wireless LAN card private
key
(NULL)
WPA/WPA2 PSK Settings
PSK ASCII
(8 - 63 characters)
PSK entered with ASCII characters (8 to
63 characters)
(NULL)
PSK Hex (64 digits) PSK entered as a hexadecimal number
(64 digits)
(NULL)
Item Setting Description Default Setting
