Canvas 088-1759-2 User Manual

4 5
PRODUCT NO. 088-1759-2
PARTS LIST
Top bar 1 - 5
Top bar 2 - 5
Connector for rail 3 - 2
Connector for rail 2 - 2
Beam 1 - 2
Tube for canopy 1 - 2
Beam 2 - 2
Tube for canopy 2 - 2
Beam 3 - 2
Beam 4 - 2
Corner connector - 4
Post 1 - 2
Post 2 - 2
Post base - 4
Base protector - 4
Arch support 1 - 4
Arch support 2 - 4
Connector for the tube of canopy - 4
Connector for rail 1 - 4
A1
A2
K3
B1
B2
B4
L2
B3
L1
C
E1
E2
G
H
I1
I2
J
K1
Guideway bar - 4
M6x15 screw - 28
Canopy - 1
M6x75 screw - 16
M6x15 bolt - 82*
Ф6 x 180 stake - 16
M6 washer - 136*
M6 wrench - 1
M6x45 screw - 10
M
DD
N
EE
AA
FF
BB
W
CC
K2
* Cumulative numbers of the hardware are
listed in the manual.
