PRODUCT NO. 088-1759-2
ASSEM BLY
E1
C
AA
BB
Step 7
Requires C, E1, E2, AA, BB, W
Attach assembled Corner connectors (C) to top of Posts (E1, E2) using M6x15
bolts (AA) and M6 washers (BB). Tighten the bolts using the wrench (W).
AA
BB
I2
B3
E1
B4
Step 8
Requires E1, E2, E3, I1, I2, AA, BB, W
Attach Arch supports (I1) at the left corners and Arch supports (I2) at the right
corners of Posts (E1, E2) and Beams (B1,B2), (B3,B4) using M6x15 bolts (AA) and
M6 washers (BB). Tighten the bolts using the wrench (W).
BB
BB
Z
Z
AA
AA
NOTE:
While assembling (C) to (E1, E2), make sure to assemble side with thread holes of
E1 and E2 toward inner of pergola, otherwise Arch supports (I1, I2) will not mount
correctly.
