ASSEM BLY
Step 1
Requires A1, A2, AA, BB, W
Insert Top bar 1s (A1) into Top bar 2s (A2), attach using M6x15 bolts (AA) and
M6 washers (BB). Tighten the bolts using the wrench (W).
Step 2
Requires B1, B2, AA, BB, W
Insert Beam 1s (B1) into Beam 2s (B2), then attach using M6x15 bolts (AA) and
M6 washers (BB). Tighten the bolts using the wrench (W).
NOTE:
When using screws and bolts to assemble the product, always use a flat washer between
the frame and the screw or bolt. This will protect the parts from wear and tear.
