Canvas 088-1759-2 User Manual

12 13
PRODUCT NO. 088-1759-2
ASSEM BLY
Step 12
Requires J, K1, K2, K3, M, BB, EE
12a) Insert one Guideway bar (M) onto one Connector for the tube of
canopy (J).
12b) Insert and attach the top end of the Guideway bars (M) with Connector
for rail 1 (K1) and lower end with Connector for rail (K2, K3) using M6x75
screws (EE) and M6 washers (BB).
EE
BB
EE
BB
K2 K3
M
J
K1
K2 K3
M
J
K1
