PRODUCT NO. 088-1759-2
ASSEM BLY
A2
B1 B2
CC
BB
A1
DD
BB
E1
G
H
E1
E1
E2
E2
Step 6
Requires E1, E2, H, G, BB, DD
Insert Posts (E1, E2) into Base protectors (H), then attach each Post base (G)
to the bottom of each Post (E1, E2) using M6x15 screws (DD) and M6 washers
(BB). Arrange the Posts (E1, E2) in a criss cross manner. Note: E1s should be
diagonal from each other.
BB
DD
Step 5
Requires A1, A2, B1, B2, BB, CC
Attach the assembled Top bars (A1, A2) to assembled Beams (B1, B2) using
M6x45 screws (CC) and M6 washers (BB).
BB
CC
