– 30 –
Maintenance
3560M-0706-040
3560M-0706-050
3560M-0706-060
Cleaning
1. Clean the ignition plug using a wire brush or plug
cleaner.
1. Grind the electrode with sandpaper to adjust the
gap as specified.
Standard clearance: 0.7 mm
3. Replace the ignition plug.
7.6.3 Fuel Cock (Fuel Filter)
Cleaning
1. Check that the fuel cock is positioned at "CLOSE".
2. Remove the fuel filter pot, and wash clean the inside
of the pot and the filter with kerosene.
To Next Page
