13
See below for full dimensional drawings of your oven to help with installation.
For a built-in oven to work effectively the cabinet must be of the right type.
The panels of the adjoining furniture should be heat-resistant. Particularly when
the adjoining furniture is made of veneered wood, the adhesives should be able
to withstand a temperature of 120ºC. Plastic materials or adhesive which cannot
withstand this temperature may become deformed or unstuck.
To comply with safety regulations, once the appliance has been fitted it should not
be possible to make contact with the electrical parts.
All parts which offer protection should be fixed in such a way that they cannot be
removed without the use of a tool.
OVEN DIMENSIONS
540mm
566mm
5mm
555mm
22mm
579mm
543mm
24mm
463mm
597mm
116mm
596mm
5mm
22mm
