Caple C2902 - Replacing the Oven Lamps; Telescopic Runners

Instruction manual C290222 Please keep this instruction manual for future reference
Inner lamp in oven cavity
REPLACING THE OVEN LAMPS
› Switch off your oven at the mains.
› Remove the glass cover of the lamp-holder by unscrewing this
› Remove the light bulb and replace it with a similar one
HALOGEN LAMP CHARACTERISTICS
› Voltage: AC220V-240V
› Wattage: 25W
› Cap: G9
Remount the glass cover and reconnect the appliance to the power supply.
DO NOT TOUCH the light bulb directly with your hands.
WARNING:
Ensure that the appliance is disconnected from the mains before replacing the lamp to avoid the
possibility of electric shock.
Left
guide rail
Right
guide rail
Direction
of extraction
TELESCOPIC RUNNERS
To assemble the telescopic runners:
› Remove the side racks
› Choose which shelf to use with the telescopic runner.
Paying attention to the direction in which the runner is
to be extracted, position joint ‘B’ and joint ‘C’ on the
frame (see Fig.1).
› Squeeze the bars together slightly and clip either
end of the telescopic runners on to the side racks.
› Finally, refit the side racks (see Fig.1).
Fig 1.
