15Instruction manual C873G, C866G & C848GPlease keep this instruction manual for future reference
CLEANING AND MAINTENANCE
Before cleaning, disconnect the appliance from the electricity supply.
Do not clean the appliance with steam cleaners.
The appliance should be cleaned only when it is cold.
GLASS CERAMIC AND STEEL PARTS
B U R N E R S AND PAN SUPPORTS
› Remove food residues and grease spatters from the cooking surface using the special
scraper (optional).
› The glass top must be washed with warm water without using abrasive powders or
corrosive substances which could ruin them.
› These parts can be removed for easier cleaning.
› The burners must be washed with a sponge and soapy water or with a mild detergent,
dried thoroughly and placed in their seat perfectly.
› Make sure that the burner cap holes are not clogged.
› Ensure the safety valve probe and ignition electrode are always clean to ensure
optimal operation.
› The pan supports can be washed in a dishwasher.
R E PLACING THE POWER SUPPLY CABLE
Should it be necessary to replace the power supply cable, use a standard type H05VV-F or
H05RR-F cable with a section of 3 x 0.75mm
2
.
The connection to the terminal board must be
carried out as shown in the figure on the right:
(live)
(neutral)
Brown wire L
Blue wire N
Green-yellow wire
(earth)
I MPORTANT: To be carried out by
qualified personnel only.
The connection to the terminal board must be carried out as shown in the figure on the right:
Green & Yellow
CLEANING AND MAINTENANCE
Before cleaning, disconnect the appliance from the electricity supply.
Do not clean the appliance with steam cleaners.
The appliance should be cleaned only when it is cold.
GLASS CERAMIC AND STEEL PARTS
B U R N E R S AND PAN SUPPORTS
› Remove food residues and grease spatters from the cooking surface using the special
scraper (optional).
› The glass top must be washed with warm water without using abrasive powders or
corrosive substances which could ruin them.
› These parts can be removed for easier cleaning.
› The burners must be washed with a sponge and soapy water or with a mild detergent,
dried thoroughly and placed in their seat perfectly.
› Make sure that the burner cap holes are not clogged.
› Ensure the safety valve probe and ignition electrode are always clean to ensure
optimal operation.
› The pan supports can be washed in a dishwasher.
R E PLACING THE POWER SUPPLY CABLE
Should it be necessary to replace the power supply cable, use a standard type H05VV-F or
H05RR-F cable with a section of 3 x 0.75mm
2
.
The connection to the terminal board must be
carried out as shown in the figure on the right:
(live)
(neutral)
Brown wire L
Blue wire N
Green-yellow wire
(earth)
I MPORTANT: To be carried out by
qualified personnel only.
Earth
Blue Neutral
Brown Live
IMPORTANT:
To be carried out by qualified personnel only.
