BUILT IN INSTALLATION
NOTE:
The wooden cabinet the appliance is to be housed in must not be enclosed. The back wooden
panel of the cabinet must be removed completely. This is to allow sufficient air circulation to
cool down the condenser unit for energy efficiency.
560mm
877 - 884mm
min 550mm
540mm
540mm
min. 50mm
827mm
40mm
8mm
Ventilation
min 200cm² in plinth
