Use
The radio programmer allows the remote control of one single phase motor 230Vac 1000W and nds
its best use in the command of automatic rolling shutters and rolling grills.
Transmitters 433 MHz Transmitters 868 MHz Description
TXQ504C2 TXQ508C2 2-channel precoded transmitters
TXQ504C4 TXQ508C4 4-channel precoded transmitters
TXQ504C8 TXQ508C8 8-channel precoded transmitters
TXQPRO504-4 TXQPRO508-4 4-channel precoded industrial transmitters
TXQPRO504-4A TXQPRO508-4A 4-channel precoded industrial transmitters + aerial
Radio programmer 433 MHz Radio programmer 868 MHz Description
RPQ504T10 RPQ508T10 Radio programmer for rolling shutters
PREPARING THE SYSTEM
Maximum range: 30 metres in open space. It is good practise to position the receiver away
from computer systems, alarm systems and other possible sources of disturbance. The radio
programmer is supplied with a wire antenna ANT (g.1) already connected to its binding post
on the circuit.
